Fertilizer Blender Production Line Features
Ground-Level Batching: Utilizes a ground-level material feeding system,
ensuring safe operations and enhancing production efficiency.
Compact Design: Features a space-saving layout, occupying approximately 50 square meters,
ideal for facilities with limited space.
Belt Conveyor System: Employs a belt conveyor for efficient material transportation,
reducing manual labor and increasing throughput.
Ribbon Mixer: Incorporates a ribbon mixer for uniform blending,
preventing material degradation and ensuring consistent quality.
Bagging System: Equipped with a bagging system for efficient packaging,
streamlining the final product preparation process.
8-Meter High Plant: Recommends a plant height of 8 meters to accommodate
equipment installation and ensure smooth operation.
Configuration List
Raw Material Storage Bins (6 units):
Used for storing and supplying raw materials,
ensuring stable storage and consistent material supply.
Static Weighing Scale (1 set):
Precisely controls the material ratios,
ensuring accurate proportioning of different raw materials.
Lifter (1 set):
Used for elevating materials, ensuring continuous transportation
of materials throughout the production process.
Mixer (1 set):
Used for blending different fertilizer materials, ensuring uniform nutrient distribution.
Bagging Machine (1 set):
Used for automated packaging, ensuring accurat
and efficient packaging of fertilizer.
Control System (1 set):
Responsible for the automation control of the entire production line,
including the batching, mixing, and packaging processes.
Product parameter：
Capacity | 10 tons/h |
Packaging scope | 25-50KG |
Types of raw materials | 3-12 |
Working power supply | AC 380V ±10% Or customized according to customers |
Air source pressure | 0.4-0.8mpa |
Suitable for temperature | 30℃ -- +40℃ |
Relative humidity | 85%R.H |
Accuracy | ± 0.2% |
Process flow chart
