Production Line Features:
Ground-Level Batching System: The fertilizer blending line uses a ground-level batching system,
eliminating the need for digging pits.
This simplifies the construction and installation process, saves space, and reduces costs.
Platform Feeding Design: The platform feeding design, with a height of approximately 2 meters,
facilitates easy operation. It is equipped with a forklift feeding system to
improve material handling efficiency and enhance safety.
Reduced Labor Cost: The production line requires only 3 to 4 operators, significantly cutting down on labor costs.
Its simple operation also reduces the need for extensive training.
Optimal Facility Height: A factory height of at least 8 meters is recommended to ensure the smooth installation
and efficient operation of equipment, providing enough space for seamless production
Product parameter：
Capacity | 15 tons/h |
Packaging scope | 25-50KG |
Types of raw materials | 3-12 |
Working power supply | AC 380V ±10% Or customized according to customers |
Air source pressure | 0.4-0.8mpa |
Suitable for temperature | 30℃ -- +40℃ |
Relative humidity | 85%R.H |
Accuracy | ± 0.2% |
Process flow chart
